MY28-A Описание
Description
| No. of Contacts | 9 |
| Part No. | MY28-9A |
|
Parts |
Material |
| Shell | Zinc Alloy |
| Finish | Nickel plating |
| Insulator | Bakelite |
| Contact | Copper Alloy |
| No.Of contacts | 9 | |
| Rated current/Voltage | 20A 380V | 10A 500V |
| Operation limt voltage(AC.Vrms) | 500 | 900 |
| Withstanding voltage(AC.V.rms)1 min. | 2000 | 4000 |
| Insulation resistance (MΩ min.)at dc 500V | ≤5000 | ≤5000 |
| Contact resistance(MΩ max.)at dc 1A | 3 | 1 |
| Solder inter diameter | 2.4×5 | 3.45×4 |
