Description
No. of Contacts | 9 |
Part No. | MY28-9A |
Parts |
Material |
Shell | Zinc Alloy |
Finish | Nickel plating |
Insulator | Bakelite |
Contact | Copper Alloy |
No.Of contacts | 9 | |
Rated current/Voltage | 20A 380V | 10A 500V |
Operation limt voltage(AC.Vrms) | 500 | 900 |
Withstanding voltage(AC.V.rms)1 min. | 2000 | 4000 |
Insulation resistance (MΩ min.)at dc 500V | ≤5000 | ≤5000 |
Contact resistance(MΩ max.)at dc 1A | 3 | 1 |
Solder inter diameter | 2.4×5 | 3.45×4 |
